Home Smart Cameras Ezviz Smart Cameras Ezviz 3MP Wi-Fi Smart Home Camera CS-C3TN
Brand: | Ezviz |
Type: | Smart Camera |
Model: | CS-C3TN-A0-1H3WKFL |
Image Sensor: | 1/2.7inch Progressive Scan CMOS |
Minimum Illumination: | 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR |
IR Night Vision Distance: | Up to 98 ft / 30 m |
Shutter Speed: | Self-adaptive shutter |
Lens: | 2.8 mm @ F2.0, view angle: 106° (Horizontal), 122°(Diagonal) |
Lens Mount: | M12 |
DNR: | 3D DNR |
WDR: | Digital WDR |
Max. Resolution: | 2MP, 1920 × 1080 |
Video Compression: | H.265 / H.264 |
Frame Rate: | Max: 30fps; Self-Adaptive during network transmission |
Wi-Fi Pairing: | AP pairing |
Protocol: | EZVIZ cloud proprietary protocol |
Wi-Fi Standard: | IEEE802.11b, 802.11g, 802.11n |
Channel Bandwidth: | Supports 20MHz |
Wired Network: | RJ45 × 1(10M / 100M Adaptive Ethernet Port) |
Transmission Rate: | 11b: 11Mbps,11g: 54Mbps,11n: 144Mbps |
Frequency Range: | 2.4GHz ~ 2.4835 GHz |
Functions: | Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
Storage: | Micro SD card slot (Max. 256 GB) |
Power: | Power Supply:DC 12V / 1A | Power Consumption:Max. 6W |
Box Content: | Charger and Screw |
Product Id: | 104101297 |
