Home Smart Cameras Ezviz Smart Cameras Ezviz 2MP Wi-Fi Smart Home Camera C3TN
Brand: | Ezviz |
Type: | Smart Camera |
Model: | CS-C3TN-A0-1H2WF |
Image Sensor: | 1/2.7inch Progressive Scan CMOS |
Minimum Illumination: | 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR |
Shutter Speed: | Self-adaptive shutter |
Lens: | 2.8 mm @ F2.0, view angle: 106° (Horizontal), 122°(Diagonal) |
Lens Mount: | M12 |
DNR: | 3D DNR |
WDR: | Digital WDR |
Video Compression: | H.265 / H.264 |
Video Bit Rate: | Ultra-HD; HD; Standard. Adaptive bit rate. |
Max. Resolution: | 1920 × 1080 |
Frame Rate: | Max: 30fps; Self-Adaptive during network transmission |
Wi-Fi Pairing: | AP Pairing |
Protocol: | EZVIZ Cloud Proprietary Protocol |
Interface Protocol: | EZVIZ Cloud Proprietary Protocol |
General Function: | Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
Max. Bitrate: | 2M |
Storage: | Micro SD card slot (Max. 256 GB) |
Wired network: | RJ45 × 1(10M/100M Adaptive Ethernet Port) |
Standard: | IEEE802.11b, 802.11g, 802.11n |
Frequency Range: | 2.4GHz ~ 2.4835 GHz |
Channel Bandwidth: | Supports 20MHz |
Security: | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
Transmission Rate: | 11b: 11Mbps,11g: 54Mbps,11n: 144Mbps |
Operating Conditions: | -4°F to 122 °F (-20ºC to 50ºC ); Humidity 95% or less ( non-condensing) |
Power Supply: | DC 12V/1A |
Power Consumption: | Max. 6W |
IP Grade: | IP 67 |
Night Vision Distance: | Max. 30 m (98 ft) |
Dimensions: | 72 × 72 × 152 mm (2.83 × 2.83 × 5.98 inch) |
Box Content: | Charger and Screw |
Product Id: | 104101280 |
