Home Smart Cameras Dahua 5MP IR Fixed-Focal WiFi Bullet Network Camera | IPC-HFW1430DT-STW - White
Brand : | Dahua |
Type: | Smart Camera |
Model: | IPC-HFW1430DT-STW |
Camera Resolution: | 2560 × 1440 |
Pixel: | 5 MP |
ROM: | 16 MB |
RAM: | 64 MB |
Electronic Shutter Speed: | Auto/Manual 1/3 s–1/100,000 s |
Scanning System: | Progressive |
Lens Focal Length: | 2.8 mm; 3.6 mm |
Max. Aperture: | F2.0 |
Field of View: | H: 80.4°, V: 58.1°, D: 104.8° |
Close Focus Distance: | 2.8 mm: 1.0 m (3.28 ft), 3.6 mm: 1.4 m (4.59 ft) |
DORI Distance: | Lens : 2.8mm, 3.6mm, Detect : 68.0 m (223.10 ft), 85.2 m (279.53 ft), Observe : 27.2 m (89.24 ft), 34.1 m (111.88 ft), Recognize : 13.6 m (44.62 ft), 17.0 m (55.77 ft), Identify : 6.8 m (22.31 ft), 8.5 m (27.89 ft) |
Video Compression: | H.264B; H.264; H.264H; H.265 |
Smart Codec: | Smart H.265+; Smart H.264+ |
Video Frame Rate: | Main stream: 2560 × 1440 (1–20 fps), Sub stream: 640 × 480@(1–25 fps) 640 × 480@(1–30 fps) |
Stream Capability: | 2 streams |
Resolution: | 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720) |
Bit Rate Control: | CBR/VBR |
Day/Night: | Auto (ICR)/Color/B/W |
Video Bit Rate: | H264: 24 kbps–4096 kbps, H265: 9 kbps–4096 kbps |
Audio Built-in MIC: | Yes |
Built-in Speaker: | Yes |
Alarm Event: | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; intensity change |
Network Port: | RJ-45 (10/100 Base-T) |
Wi-Fi: | IEEE802.11b/g/n 2.4–2.4835 GHz; 2.4 G |
Wireless Range: | Up to 150 m (The performance varies based on actual environment) |
User/Host: | 6 (Total bandwidth: 36 M) |
Storage: | Micro SD card (support max. 256 GB) |
Power Supply: | 12 VDC |
Power Consumption: | Basic: 2.1 W (12 VDC) Max. (H.265+IR intensity):6.1 W (12 VDC) |
Casing: | Front cover: Plastic, Rear: Plastic, Bracket: Metal |
Dimensions: | 180 mm × 83.3 mm × 114.8 mm |
Weight: | 350.1 g |
Box Content: | . |
Product ID: | 104104140 |
